Thermal shock chambers global

electrical thermostat incubator for sale

Product Description


Equipment summary:

Professional thermal shock testing chambers for sales used to test the change of material under extremely high temperature and extremely low temperature environment that continue alternation in the shortest time,

Testing the chemical changes or physical damage of material caused by the thermal expansion and contraction. Testing box divided two parts, one is high-temperature region, another is low-temperature

region, the testing sample placed on the moving basket, using unique heat storage and cool storage,

the cylinder taking basket moves up and down in the hot and cold region to complete the hot and cold temperature impact testing; applied to test the material, including metal, plastic, rubber, electronics ….

and other materials, it can be used as a basis for improvement of their products.

Corresponding standard:

1 GB/T2423.1-1989 low-temperature testing method
2 GB/T2423.2-1989 high-temperature testing method
3 GB/T2423.22-1989  change temperature test
4 GJB150.5-86  temperature impact test
5 GJB360.7-87  temperature impact test
6 GJB367.2-87 405 temperature impact test


Applicable industries:

Professional thermal shock testing chambers for sales   widely used in aviation, military,  ships, electrical, electronics, instruments and meters; medical equipment; civilian nuclear energy; colleges and universities; research laboratories; commodity inspection, arbitration, technical supervision departments; building materials ceramic; petroleum and chemical products, machine and spare parts.


Technical parameters:

Model ZME-2012A Professional thermal shock testing chambers for sales
Temperature range A.high-temperature : +60 degree to +150 degree
B.low-temperature : -10 degree to -40 degree
Control temperature ±2 degree
resolution 0.01 degree
Heating time at high-temperature region From RT to 150 about 35min (RT is from 5 degree to 30 degree).
Cooling time at low-temperature region From RT to -40 degree about 50min (RT is from 5 degree to 30 degree)
Moving time and temperature recover time A. testing bastet moving from high-temperature to low-temperature spend 10sec
B.after exchanging the temperature,the tempreature recovery time: 3min to 5min  (Stabilization time ≥ 30min)
Device noise Below 75dB.
Weight 10Kg
Testing region(hot and cold) 50cm(W)*50cm(H)*50cm(D)
Outside size 140cm(W)*180cm(H)*142cm(D)
Testing basket size 30cm(W)*40cm(H)*30cm(D)
Inside material SUS#304 Cold-Heat-resistant stainless steel
Outside material                 SUS#304 Cold-Heat-resistant stainless steel
Insolution material High-density glass wool and high strength PU foam insulation
Anti-sweat structure insulation layer and door micro-thermal anti-sweat
Expansion Heat reach 300 degree,cold reach -100 degree
