thermostatic drying oven

Thermal shock chambers internationalprogrammable temperature thermal shock chambers

Product Description

programmable temperature thermal shock chambers can be used in testing composite material and material structure’s result which under continuous environment with high temperature or low temperature shock in short time; it means thisproduct can test the material’s chemical change or physics change by expansion and contraction within short time. It’s application to metal, plastic, rubber, electronic etc materials and can be used for product improvement’s reference.

Product features:

1)  Perfect outlook upgrades, easy operation

2)  The color touch microcomputer temperature controller was made in Japan which can display Chinese / English Vertical structure with 3 chambers, high low temperature shock cycling can be automatic control, remain and change time can be adjustable, stainless steel inner material, several record methods, it has various safety precautions and device.

3)  Perfect protect alarming function: when it has condition with short circuit, work chamber over-temperature, leakage; compressor with over-pressure, over-load, oil pressure, water-break, the screen will automatic display the fault cause and provide exclusion method, and when the input voltage is unstable, programmable temperature thermal shock chambers  due to it has the stop device that the remove time of high-low temperature shock structure within 10s.

4)  The recovery time for this product within 5min and meet MTL, IEC, JIS, GJB etc standard.


Option accessories:

Ln2 fast cooling control system

RS-232 RS-232C communication interface device, it can supervisory control and record by LAN with computer together

Functional module:

1)  This equipment divided into three sections: hot chamber, cold chamber and testing chamber. It’s using unique the heat protection structure, accumulation of hot and cold effect, heat and cold air course to guide into the specimen to make the temperature shock test.

2)  The color touch microcomputer temperature controller(320*240dots) was made in Japan

3)  High formula memory capacity may be set to 100 groups. The maximum cycle setting is 9999cycles. The maximum setting of each section is 999 Hrs 59 Min.

4)  Provide with RS-232C communication interface device, capable of controlling / editing/ recording in the linkage with the computer and two set dynamic connection point and convenient application. Both 2 zone and 3 zone chambers can be chosen.

5)  It is the fully automatic and high precision program, and all process are precisely controlled by P.L.C.’S.

6)  For the malfunctions, the machine will automatically shuts down and a warning light switches on. It can be shut down automatically in case of electrical power instabilities

The main parameters:

Inside dimension:36×35×40cm(can be customized)

Outside dimension: 151×182×142cm

Test method: pneumatic door change into 2 zones or 3 zones shock chamber method

The hot chamber preheating temperature range: 60~200°C

Heating rate: 60→200°C about 20min

The cold chamber pre-cooling temperature range:-78→0°C

Cooling rate:20→-75°C about 70min

Test chamber temperature deviation: ±2°C

Temperature range: A:-40°C~+150°C,B:-55°C~150°C,C:-65°C~+150°C

Temperature recovery time: within 5min

The carrying capacity of specimen shelf: 30Kg

Specimen weight: 5 Kg

Material: Exterior material is cold-roll steel sheets with rust prevention or SUS#304 Stainless steel plate; Interior material is SUS#304 Stainless steel plate, heat-insulating material is PU foam and fiberglass

1) The hot chamber

Heater: nicochrome electric heater

Ventilator: centrifugal ventilator when exposed in high temperature or environment temperature, axial flow ventilator for preheating

2)The cold chambe

Heater, cooler; nicochrome electric heater, regenerator

Ventilator: centrifugal ventilator

3)  Device

Pneumatic cylinder: it can be used in each device when exposed for hot temperature, environment temperature, cold temperature

Air compressor: provide the compress air for pneumatic ventilator (option)

4)Refrigerating unit

Cooling method: cascade refrigeration system

Refrigeration compressor: semi-closed piston

Freezing medium: R23/R404 environmental friendly
