Thermal shock chambers kansas Thermal Shock Chambers
Equipment summary:
Thermal Shock Chambers is divided into high temperature area, low temperature area and test area three parts, each area is a unique insulation structure, so doing hot and cold impact test. High-temperature impact test or low-temperature impact test, the maximum time is up to 9999 minutes, the most cycle time is up to 9999 times. The machine can be automatically or manually cycle the impact or selectively set the two areas or three areas to impact of hot and cold. It used binary cooling system that is very effectiveness for cooling, the cooling system is divided into the air-cooled and water-cooled. It also can be connected with a computer, but the record instrument is only for optional purchase. Color LCD touch-control operation interface with Chinese and English, easy to operate.
Corresponding standard:
1,GB/T2423.1-1989 low-temperature testing method;
2,GB/T2423.2-1989 high-temperature testing method;
3,GB/T2423.22-1989 temperature test;
4,GJB150.5-86 temperature impact test;
5,GJB360.7-87 temperature impact test;
6,GJB367.2-87 405 temperature impact test.
Applicable industries:
Thermal Shock Chambers is applied to aviation, military, ships, electrical, electronics, instruments and meters; medical equipment; civilian nuclear energy; colleges and universities; research laboratories; commodity inspection, arbitration, and technical supervision departments; building materials ceramic; petroleum and chemical products, For high and low temperature impact test
Techincal parameter:
| Model | 2012-49A | 2012-80A | 2012-150A | 2012-49B | 2012-80B | 2012-150B | 2012-49C | 2012-80C | 2012-150C | |
| size (W*H*D) mm |
Inner box | 35×35×40 | 50×40×40 | 60×50×50 | 35×35×40 | 50×40×40 | 60×50×50 | 35×35×40 | 50×40×40 | 60×50×50 |
| Outer box | 150*195*145 | 180*200*145 | 190*200*155 | 150*195*145 | 180*200*145 | 190*200*155 | 1501*95*145 | 180*200*145 | 190*200*155 | |
| Cooling time | 20°C~-55°C about 60min | 20°C~-65°C about 75min | 20°C~-75°C about 90min | |||||||
| Impact recover time | High-temperature(150°C)about 30min | |||||||||
| Low-temperature(-40°Cor-55°Cor-60°C)about 30min | ||||||||||
| Impact recover time 5min | ||||||||||
| weight | 2.5kg | 5kg | 10kg | 25kg | 5kg | 10kg | 2.5kg | 5kg | 10kg | |
| Inner material | SUS # 304 stainless steel | |||||||||
| Outer material | US #304 stainless steel | |||||||||
| insulation | High-precision glass wool + PU foam rubber | |||||||||
